However on the FTDX5000 or if you are using the RS232 connection on the radios you must use CAT control or VOX. This is easy to do on the FT-991, FTDX-1200, FTDX-3000, and the FTDX-10/101 if you are using the built in USB connection or using an SCU-17. The best way and easiest to configure is using DTR on a separate comport, not the comport used for CAT control. There are a number of possibilities here.
FSQ FLDIGI UPDATE
As of the current update (July 2021), HamLib seems to finally work correctly.
One can use Omni-rig as the rig or the actual HamLib rig configuration.
FSQ FLDIGI SERIAL
Connect directly to the radio and once you everything is working correctly, then just change the Serial port definition to correspond with the com0com pair as shown in the concept section. The best way to approach configure this is to start with Win4Yaesu out of the picture. Pay attention to the checked “Use RigCat”, checked CAT command for PTT and the unchecked RTS/CTS flow control. Here the device is set to COM14 from a previously created COM14-COM15 virtual pair. Select Configure, Rig Control from the FLDIGI screen. So you can enter the path and filename of DXCommander and it will automatically start when you start Win4Yaesu Suite. The screen shot shows the filenames for Ham Radio Deluxe, but any program can be entered here. You will also notice that there are two lines in the HRD section which allow you to save the name of a file that will start when Win4K3Suite starts.
FSQ FLDIGI SOFTWARE
You can use the same principle for any other third party software such as N1MM, DX4Win and so on. Therefore everything that is supported in DXLabs Suite also works. From the point of view of DXCommander, all it sees is a Yaesu radio connected to its comport. Next click on the Ports tab and enter Port# 11 corresponding to the serial port of the virtual comport pair you created above.Įxit out and you should be connected to DXCommander. You will then see see the following screen. Select Config from the main DXCommander screen: Third Party Software Setup DX CommanderĪs an example, DXCommander from DXLab Suite is configured as follows. In addition, VSPE does not work with OmniRig which is a common CAT interface for many programs. Please note that while these work, none are as stable as COM0COM. There are other packages available that create virtual comport pairs such as one from Eltima ($$) and VSPE. If you wish to connect a hardware device to your system such as an antenna tuner that supports Yaeus FTDX or Kenwood radios, just plug it into an available serial port on your computer and enter that comport number in one of the AUX/CAT ports. This has effectively connected the two products together via a null modem cable. The others are currently to other virtual port pairs.Īll you need to do now is save the settings and then configure your third party product to connect to comport 11 which is the second comport of the COM11-COM18 pair. In this example, AUX/CAT Port 1 is connected to comport 18. Each one can connect to a comport of a virtual comport pair. In this screen there are 4 AUX/CAT ports. Once the comport pair is created, start up Win4Yaesu Suite and select Tools, Settings, and the 3rd Party SW/HW tab. Please note that many older software packages may not know about comports with numbers higher than COM9. In the above I chose COM18 and COM11 for one pair and COM20 and COM21 for another. You can just click on the names and change the names of the comports to a comport name that does not exist on your system. There will be by default one pair already defined with weird letter names.
FSQ FLDIGI HOW TO
If you do this, contact support for how to fix the errors (for those in the know, use the device manager and delete the driver file, then reinstall).Īfter you install this, open the Windows start menu and in the com0com folder run “Setup.” (Don’t run Setup Command line).
FSQ FLDIGI DOWNLOAD
If you download a newer version that is NOT signed you will have many errors even if you uninstall it and then try to install this version. The recommended utility which is free, is COM0COM which is open source and available at:īe sure to use the version for your operating system. In order to use this feature you will need to download a third party utility that provides virtual serial port pairs to Windows. These ports provide an interface that for all purposes look just like a Yaesu FTDX to the third party product. Win4Yaesu Suite supports many third party products by providing 4 auxiliary ports that accept CAT commands. You can also check out the video tutorials. Please take a few minutes to understand the concept below. Win4Yaesu Suite has a robust and trouble free comport sharing mechanism built in.
